TENS DUAL CHANNEL

Battery operated, Digital display, reusable electrodes.

The Combo unit integrates EMS and TENS functions with 7 treatment modes. This unit is a hybrid stimulator which can be used for muscle stimulation and pain relief.

  1. Channel - Dual
  2. Intensity - 0 ~ 80mA
  3. Wave form - Asymmetrical rectangular biphasic pulse.
  4. Power source - DC 9V
  5. Size - 13.6(L)x7(W)x2.65(H)(cm)
  6. Weight - 162 grams (battery included)
  7. Pulse Rate - 2Hz~20 Hz in 1 Hz/step and 20~ 150 Hz in 5 Hz/step.
  8. Pulse Width - 50uS~300uS, 10uS/step.
  9. Output mode - S, A, N, M, B, SD, MR
  10. Contraction Time - 2~90 seconds
  11. Relaxation Time - 2~90 seconds
  12. Ramp Time - 1~8 seconds
  13. Timer - 5~90 Minutes or continue.
  14. Electrode Detection - Option function, Only active in Pulse Width between from 100uS and 300uS.
  15. Compliance Timer - The patient compliance timer can memorize 100 sets of therapy session records; the total record time is 400 hours; 240 minutes for a single therapy session.
